ITEM SPECIFICATION
Rated Voltage 12.0 VDC
Starting Voltage N/A
Operating Voltage Range 11.4V~12.6V
Rated Current Max.0.50A Duty cycle =100%
Rated Power Max.6.00W Duty cycle =100%
Start Peak Current N/A
UL Current On Label 0.50 A
Rated Speed
500±300 R.P.M Duty cycle =0%
2800±300R.P.M Duty cycle =100 %
(Testing Speed After Continuous 3Minutes Operation At Ambient Temperature Of 25℃)
Air Flow(At Zero Static Pressure)
13.09 CFM (Min. 11.69 CFM)0.37 m³/min (Min. 0.33 m³/min）(REF) Duty cycle =100%
Static Pressure(At Zero Flow)
15.76 mmH2O (Min. 12.56 mmH2O)0.62 Inh-H2O (Min.0.49 Inh-H2O)(REF) Duty cycle =100%
Sound Level 36.5 dB(A) [Max. 39.0 dB(A)]
Product Type ■ RoHS □ HF
Life Expectancy 40,000 Hours at 25℃.
Bearing Type □ Two Ball ■ EBR □ Ball And Sleeve
