ITEM SPECIFICATION:
Rated Voltage 5.0 VDC
Starting Voltage 3V(25deg.C Power ON/OFF)
Operating Voltage Range 3V~5.5V
Rated Current Max.0.40A Duty cycle =100%
Rated Power Max.2.00W Duty cycle =100%
Start Peak Current N/A
UL Current On Label 0.34 A
Rated Speed
0 R.P.M Duty cycle =0%
4500±10% R.P.M Duty cycle =100 %(Testing Speed After Continuous 3Minutes Operation At Ambient Temperature Of 25℃)
Air Flow(At Zero Static Pressure)
4.68 CFM (Min. 4.21CFM)0.13 m³/min (Min. 0.12 m³/min） Duty cycle =100%
Static Pressure(At Zero Flow)
15.23 mmH2O (Min. 12.34 mmH2O)0.60 Inh-H2O (Min. 0.49 Inh-H2O) Duty cycle =100%
Sound Level 32.5 dB(A) (Max. 35.0 dB(A))
Product Type ■ RoHS □ HF
Life Expectancy 40,000 Hours at 25℃.
Bearing Type □ Two Ball ■ EBR □
