ITEM SPECIFICATION
Rated Voltage 5.0 VDC
Starting Voltage N/A
Operating Voltage Range 4.5V~5.5V
Rated Current Max.0.30A Duty cycle =100%
Rated Power Max.1.50W Duty cycle =100%
Start Peak Current N/A
UL Current On Label 0.34 A
Rated Speed
0 R.P.M Duty cycle =0%
4200±10% R.P.M Duty cycle =100%(Testing Speed After Continuous 3Minutes Operation At Ambient Temperature Of 25℃)
Air Flow(At Zero Static Pressure)
5.24 CFM (Min. 4.36 CFM)0.15 m³/min (Min. 0.12 m³/min） Duty cycle =100%
Static Pressure(At Zero Flow)
9.32 mmH2O (Min. 6.44 mmH2O)0.37 Inh-H2O (Min. 0.25 Inh-H2O) Duty cycle =100%
Sound Level 32.0 dB(A) (Max. 36.0 dB(A))
Product Type ■ RoHS □ HF
Life Expectancy 40,000 Hours at 25℃.
Bearing Type □ Two Ball ■ EBR □ Ball And Sleeve
