ITEM SPECIFICATION
Rated Voltage ■5V □ 12V □ 24V □ 48V
Starting Voltage 3V(25deg.C Power ON/OFF)
Operating Voltage Range 3V~5.5V
Rated Power 3.00W (MAX.3.00W) Duty cycle =100%
Rated Current 0.60Amp (MAX.0.60Amp) Duty cycle =100%
Rated Speed
4500RPM ±15% Duty cycle =100%
0 RPM Duty cycle =0%
(Testing Speed After Continuous 3Minute Operation At Ambient Temperature Of 25℃)
Air Flow
4.20CFM 0.12m3/min(REF) Duty cycle =100%
Sound Level
MAX.43 dB(A) Duty cycle =100%
Static Pressure
19.00mmH2O (REF) Duty cycle =100%
Life Expectancy
□40,000hours at 40℃ ■ 30,000hours at 20℃
Bearing Type
□Two Ball □ Ball And Sleeve
■ EBR □ One Ball
Product Type
■ Rohs□ HF □ GP
Protection □Impedance Protection ■Auto-Restart □Current-Limit
